◎   상세스펙

Analog Inputs : MIC In : 16 x XLR Balanced (ch 1-16)

Line In : 16 x TRS Balanced jacks (Ch 1-16)

- Insert I/O : 16 x Phone jacks (Unbalanced)

- 2TR IN Analog : 2 x RCA (Unbalanced)

- Stereo Output : 2 x XLR Balanced, 2 x RCA (Unbalanced)

- Main Output : 2 x XLR Balanced

- Control Room Output : 2 x XLR Balanced

- Multi Outputs : 8 x TRS Balanced

- AUX/Group Output : 8 x TRS Balanced (Shared through Multi)

- Phones : 1 x Stereo Phone jack (TRS Unbalanced)

- Digital I/O : (AES/EBU) 2 x XLR Balanced

- Sampling Frequency : 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz

(40-Bit Floating Point Mixing)

- Signal Delay (CH INPUT to STEREO OUT)

: Fs=48 kHz <1.2ms, Fs=96 kHz <0.6ms

- Faders : 17 x 100mm motorized faders

- Word Clock I/O : 2 x BNC Connectors

- Distortion (THD + N) : THD+N less than 0.007%, +4 dBu, 20-20 kHz,

unity gain, 20 kHz BW

- Frequency Response(CH INPUT to STEREO OUT)

: Fs=48, 96kHz, 0/-1.5dBu, 20 Hz ?. 20 kHz @ +4dBu into 600Ω

- Hum & Noise : (20 Hz ?20 kHz), Rs=150, -128dBu (EIN),

-90dBu (residual output noise)

- Optional Expansion Card : A standalone 16-channel PCM WAV recorder and a Firewire/USB 2.0 multitrack recording

audio interface; USB 3.0 flash drives compatible

- VGA Monitor output : D-Sub 15 pin: Progressive scan up to

1024x768p@60Hz (XGA)

- Ethernet 10/100 Base : RJ45

- USB 2.0 MIDI : Type B

- USB 2.0 (Mouse and Wi-Fi) : Type A x 2

- Power Supply Unit : 100V ?240V, 50/60 Hz, 90W

- Dimensions (H x W x D) : 164 x 495 x 534 mm（6.46" x 1935" x 21")

- Weight : 17.0 kg (37.5 Ibs)
